Forwarder cranes

For modern forestry

Cranab forwarder cranes are designed for the forestry industry. Thanks to their booms, they can work close to the carrier and over an increased work area, as well as provide optimum height and lifting capacity.

The FC series brings precision and dependability to forestry machines. Low weight and a compact construction were highly-prioritised factors during the development phase. Creating a complete and well-planned driving experience, with efficiency at every step, every day. It has fingertip sensitivity right the way out to the log, giving you the right speed and fluidity of motion.

It only takes a matter of seconds for the FC6 to leave a memorable impression. Almost immediately, you’ll see it is made with great care, with excellent running characteristics and a user-friendly operator’s station begging to be put to good use.
The crane lifts heavier loads higher and faster and with greater precision than ever before.

{loadposition download-pdf-forwarder}



Available versions:

Max. reach 10 m
Lifting torque, gross 67 kNm
Max. lifting force 5,5 kN

The FC series brings precision and dependability to forestry machines. Low weight and a compact construction were highly-prioritised factors during the development phase. Creating a complete and well-planned driving experience, with efficiency at every step, every day. It has fingertip sensitivity right the way out to the log, giving you the right speed and fluidity of motion.

It only takes a matter of seconds for the FC8 to leave a memorable impression. Almost immediately, you’ll see it is made with great care, with excellent running characteristics and a user-friendly operator’s station begging to be put to good use.
The crane lifts heavier loads higher and faster and with greater precision than ever before.

{loadposition download-pdf-forwarder}



Available versions:

Max. reach 10 m
Lifting torque, gross 87 kNm
Max. lifting force 7,6 kN

The FC series brings precision and dependability to forestry machines. Low weight and a compact construction were highly-prioritised factors during the development phase. Creating a complete and well-planned driving experience, with efficiency at every step, every day. It has fingertip sensitivity right the way out to the log, giving you the right speed and fluidity of motion.

It only takes a matter of seconds for the FC10 to leave a memorable impression. Almost immediately, you’ll see it is made with great care, with excellent running characteristics and a user-friendly operator’s station begging to be put to good use.
The crane lifts heavier loads higher and faster and with greater precision than ever before.

{loadposition download-pdf-forwarder}



Available versions:

Max. reach 10 m
Lifting torque, gross 100 kNm
Max. lifting force 7,2 kN

The FC series brings precision and dependability to forestry machines. Low weight and a compact construction were highly-prioritised factors during the development phase. Creating a complete and well-planned driving experience, with efficiency at every step, every day. It has fingertip sensitivity right the way out to the log, giving you the right speed and fluidity of motion.

It only takes a matter of seconds for the FC12 to leave a memorable impression. Almost immediately, you’ll see it is made with great care, with excellent running characteristics and a user-friendly operator’s station begging to be put to good use.
The crane lifts heavier loads higher and faster and with greater precision than ever before.

{loadposition download-pdf-forwarder}



Tekniska specifikationer:

Max. reach 10 m
Lifting torque, gross 120 kNm
Max. lifting force 9,7 kN

The FC series brings precision and dependability to forestry machines. Low weight and a compact construction were highly-prioritised factors during the development phase. Creating a complete and well-planned driving experience, with efficiency at every step, every day. It has fingertip sensitivity right the way out to the log, giving you the right speed and fluidity of motion.

It only takes a matter of seconds for the FC16 to leave a memorable impression. Almost immediately, you’ll see it is made with great care, with excellent running characteristics and a user-friendly operator’s station begging to be put to good use.
The crane lifts heavier loads higher and faster and with greater precision than ever before.

{loadposition download-pdf-forwarder}



Available versions:

Max. reach 10 m
Lifting torque, gross 165 kNm
Max lifting force 36 kN
The Cranab FC45 is developed with the professional demands of the forest in mind, with quality down to the finest detail. It is suitable for smaller forwarders and agricultural tractors.
The Cranab FC45 is available in two versions, with either a single or double telescopic outer boom. The latter offers excellent reach, for thinning. The linking outer boom ensures a wide field of movement, with equal power throughout the entire area. The construction is robust yet light, and is suited to many different kinds of application. The slewing assembly naturally has double slewing cylinders for extra power.
As always, Cranab’s well-routed hosing provides superior operating reliability and fluidity. Various valve options can be supplied, mounted in a practical way directly on the foot of the crane.

{loadposition download-pdf-fc45}



Available versions:

Max. reach 8 m
Lifting torque, gross 45,6 kNm
Max. lifting force 5,6 kN
Cranab FC53 is the crane of choice for small forwarders or large forestry wagons. It is also well-suited for direct mounting on large agricultural tractors. Uncompromising design in combination with Cranab’s production quality give FC53 the best possible footing.
The crane has been designed using the highest quality materials, well dimensioned bearing seatings and cylinders developed for intensive work. Protected hose routing and high quality hoses ensure little downtime and trouble free operations. A slewing motor with double gear racks allow for exact positioning as well as a long life.
Cranab FC53 is a crane designed for those seeking a fast, small crane with the feautures of a large crane.

{loadposition download-pdf-fc53}



Available versions:

Max. reach 8,5 m
Lifting torque, gross 53 kNm
Max. lifting force 6,2 kN
Telescopic versions1
Max. reach7,2 m
Lifting torque, gross67 kNm
Lifting force at max. reach5,5 kN
Boom extension1,7 m
Gross slewing torque 22,0 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow90 - 150 l/min
Weight with lowest pillar elevation1235 kg
Telescopic versions2
Max. reach9,2 m
Lifting torque, gross67 kNm
Lifting force at max. reach3,4 kN
Boom extension3,4 m
Gross slewing torque 22,0 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow90 - 150 l/min
Weight with lowest pillar elevation1350 kg
Telescopic versions2
Max. reach10,0 m
Lifting torque, gross67 kNm
Lifting force at max. reach2,7 kN
Boom extension4,0 m
Gross slewing torque 22,0 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow90 - 150 l/min
Weight with lowest pillar elevation1400 kg
Telescopic versions1
Max. reach7,4 m
Lifting torque, gross87 kNm
Lifting force at max. reach7,6 kN
Boom extension1,7 m
Gross slewing torque 22,0 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow90 - 150 l/min
Weight with lowest pillar elevation1235 kg
Telescopic versions2
Max. reach9,2 m
Lifting torque, gross87 kNm
Lifting force at max. reach5,4 kN
Boom extension3,4 m
Gross slewing torque 22,0 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow90 - 150 l/min
Weight with lowest pillar elevation1350 kg
Telescopic versions2
Max. reach10,0 m
Lifting torque, gross87 kNm
Lifting force at max. reach4,6 kN
Boom extension4,0 m
Gross slewing torque 22,0 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow90 - 150 l/min
Weight with lowest pillar elevation1400 kg
Telescopic versions1
Max. reach8,0 m
Lifting torque, gross100 kNm
Lifting force at max. reach7,2 kN
Boom extension2,0 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow120 - 200 l/min
Weight with lowest pillar elevation1610 kg
Telescopic versions1
Max. reach8,5 m
Lifting torque, gross100 kNm
Lifting force at max. reach6,5 kN
Boom extension2,4 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow120 - 200 l/min
Weight with lowest pillar elevation1630 kg
Telescopic versions2
Max. reach9,8 m
Lifting torque, gross100 kNm
Lifting force at max. reach2,7 kN
Boom extension4,0 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow120 - 200 l/min
Weight with lowest pillar elevation1735 kg
Telescopic versions2
Max. reach10,0 m
Lifting torque, gross100 kNm
Lifting force at max. reach4,8 kN
Boom extension4,0 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow120 - 200 l/min
Weight with lowest pillar elevation1745 kg
Telescopic versions1
Max. reach8,0 m
Lifting torque, gross120 kNm
Lifting force at max. reach9,7 kN
Boom extension2,0 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure24,5 Mpa
Recommended flow130 - 220 l/min
Weight with lowest pillar elevation1630 kg
Telescopic versions1
Max. reach8,5 m
Lifting torque, gross120 kNm
Lifting force at max. reach8,8 kN
Boom extension2,4 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure24,5 Mpa
Recommended flow130 - 220 l/min
Weight with lowest pillar elevation1650 kg
Telescopic versions2
Max. reach9,8 m
Lifting torque, gross120 kNm
Lifting force at max. reach7,1 kN
Boom extension4,0 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure24,5 Mpa
Recommended flow130 - 220 l/min
Weight with lowest pillar elevation1755 kg
Telescopic versions2
Max. reach10,0 m
Lifting torque, gross120 kNm
Lifting force at max. reach6,7 kN
Boom extension4,0 m
Gross slewing torque 28,7 kNm
Angle of rotation370°
Working pressure24,5 Mpa
Recommended flow130 - 220 l/min
Weight with lowest pillar elevation1765 kg
Telescopic versions1
Max. reach8,5 m
Lifting torque, gross165 kNm
Lifting force at max. reach12,8 kN
Boom extension2,0 m
Gross slewing torque 42,5 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow180 - 300 l/min
Weight with lowest pillar elevation2200 kg
Telescopic versions2
Max. reach10,0 m
Lifting torque, gross165 kNm
Lifting force at max. reach9,8 kN
Boom extension3,7 m
Gross slewing torque 42,5 kNm
Angle of rotation370°
Working pressure23,5 Mpa
Recommended flow180 - 300 l/min
Weight with lowest pillar elevation2385 kg
Telescopic versions1
Max. reach6,1 m
Lifting torque, gross45,6 kNm
Lifting force at max. reach5,6 kN
Boom extension1,55 m
Gross slewing torque 13,0 kNm
Angle of rotation380°
Working pressure19,0 Mpa
Recommended flow40 - 80 l/min
Weight with lowest pillar elevation650 kg
Telescopic versions2
Max. reach8,0 m
Lifting torque, gross45,6 kNm
Lifting force at max. reach3,5 kN
Boom extension3,21 m
Gross slewing torque 13,0 kNm
Angle of rotation380°
Working pressure19,0 Mpa
Recommended flow40 - 80 l/min
Weight with lowest pillar elevation795 kg
Telescopic versions1
Max. reach6,5 m
Lifting torque, gross53 kNm
Lifting force at max. reach6,2 kN
Boom extension1,55 m
Gross slewing torque 12,0 kNm
Angle of rotation380°
Working pressure18,5 Mpa
Recommended flow40 - 80 l/min
Weight with lowest pillar elevation720 kg
Telescopic versions2
Max. reach8,5 m
Lifting torque, gross53 kNm
Lifting force at max. reach4,1 kN
Boom extension3,21 m
Gross slewing torque 12,0 kNm
Angle of rotation380°
Working pressure18,5 Mpa
Recommended flow40 - 80 l/min
Weight with lowest pillar elevation870 kg
