FC8

The FC series brings precision and dependability to forestry machines. Low weight and a compact construction were highly-prioritised factors during the development phase. Creating a complete and well-planned driving experience, with efficiency at every step, every day. It has fingertip sensitivity right the way out to the log, giving you the right speed and fluidity of motion.

It only takes a matter of seconds for the FC8 to leave a memorable impression. Almost immediately, you’ll see it is made with great care, with excellent running characteristics and a user-friendly operator’s station begging to be put to good use.

The crane lifts heavier loads higher and faster and with greater precision than ever before.

Technical specifications:

FC8 - Version 1
Telescopic version
1
Max. reach
7,4 m
Lifting torque, gross
87 kNm
Lifting force at max. reach
7,6 kN
Boom extension
1,7 m
Gross slewing torque
22,0 kNm
Angle of rotation
370°
Working pressure
23,5 MPa
Recommended flow
90 - 150 l/min
Weight with lowest pillar elevation
1235 kg
FC8 - Version 2
Telescopic version
2
Max. reach
9,2 m
Lifting torque, gross
87 kNm
Lifting force at max. reach
5,4 kN
Boom extension
3,4 m
Gross slewing torque
22,0 kNm
Angle of rotation
370°
Working pressure
23,5 MPa
Recommended flow
90 - 150 l/min
Weight with lowest pillar elevation
1350 kg
FC8 - Version 3
Telescopic version
2
Max. reach
10,0 m
Lifting torque, gross
87 kNm
Lifting force at max. reach
4,6 kN
Boom extension
4,0 m
Gross slewing torque
22,0 kNm
Angle of rotation
370°
Working pressure
23,5 MPa
Recommended flow
90 - 150 l/min
Weight with lowest pillar elevation
1400 kg
