Cranab truck crane RZ18

RZ18

With Cranab's RZ cranes, every operator quickly becomes productive right from the start.

The RZ18 is available in four versions from 8.3 metres to 10.15 metres and covers the needs of most users.

Download PDF





Available versions:

Max. standard reach 10,2 m
Max. lifting capacity 171,0 kNm
Max. hydraulic extension 3,7 m

Telescopic version1
Standard reach8,3 m
Lifting capacity182,00 kNm
Hydraulic extension1,85 m
Angle rotation425°
Rotation torque29,3 kNm
Working pressure26 Mpa
Pump capacity120 - 160 l/min
Crane weight2910 kg

Telescopic version2
Standard reach10,15 m
Lifting capacity171,00 kNm
Hydraulic extension3,7 m
Angle rotation425°
Rotation torque29,3 kNm
Working pressure26 Mpa
Pump capacity120 - 160 l/min
Crane weight3000 kg

Telescopic version2
Standard reach8,3 m
Lifting capacity172,00 kNm
Hydraulic extension1,85 m
Angle rotation425°
Rotation torque29,3 kNm
Working pressure26 Mpa
Pump capacity120 - 160 l/min
Crane weight2850 kg
